DC Screw Solar Water Pump

Our DC Screw Solar Water Pump is specially designed for deep well water lifting where high head and stable discharge are required. Powered by solar energy through a dedicated DC controller, it is a reliable solution for off-grid water supply, livestock watering, rural drinking water systems, and small agricultural irrigation projects.

This series features a brushless DC motor, screw pumping structure, stainless steel oil cylinder, and NSK bearing design for efficient operation and long service life. Compared with standard impeller pumps, screw solar pumps are especially suitable for deep wells and applications requiring higher head with relatively lower flow.

2 inch, 3 inch, and 4 inch brushless DC screw solar pump options
Ideal for deep well and high head water pumping applications
Brushless DC motor for stable and energy-saving operation
Screw structure for reliable clean water delivery
Compatible with solar panels and DC controller systems

Product Overview

Product Name	DC Screw Solar Water Pump	Series	2DSS / 3DSS / 4DSS
Type	Brushless DC Screw Solar Pump	Pump Diameter	2 Inch / 3 Inch / 4 Inch
Pump Structure	Screw Pump	Bearing	NSK Bearing
Main Material	Stainless Steel	Oil Cylinder	Stainless Steel Oil Cylinder
Power Supply	Solar Panel + DC Controller	Typical Application	Deep Well Water Supply, Household Use, Irrigation, Livestock Watering
Package	Export Standard Packing	Warranty	2 Years

DC Screw Solar Water Pump Structure Image

Product Structure / Parts Detail

Key Features

Brushless DC motor for efficient and smooth performance
Screw pumping structure suitable for deep well applications
Higher head output for long vertical lifting distance
Stainless steel body for corrosion resistance and durability
NSK bearing for reliable long-term operation
Works with solar panels through a dedicated controller
Suitable for remote areas without stable grid power
Low maintenance and easy system integration

Technical Data

Model	Voltage	Optimum Input Voltage (DC)	Power	Max. Flow	Max. Head	Outlet	Cable	Open Circuit Voltage (VOC)	Recommended Solar Panel Power
2DSS1.2-56-24-120	24V	30V–48V	120W	1.2 m³/h	56m	0.5"	2m	<60V	≥1.3 × Pump Power
2DSS1.5-75-36-210	36V	30V–48V	210W	1.5 m³/h	75m	0.5"	2m	<60V	≥1.3 × Pump Power
2DSS1.7-100-48-500	48V	60V–90V	500W	1.7 m³/h	100m	0.5"	2m	<110V	≥1.3 × Pump Power
3DSS0.5-28-12-80	12V	30V–48V	80W	0.5 m³/h	28m	0.75"	2m	<60V	≥1.3 × Pump Power
3DSS1.2-56-24-120	24V	30V–48V	120W	1.2 m³/h	56m	0.75"	2m	<60V	≥1.3 × Pump Power
3DSS1.2-77-36-210	36V	30V–48V	210W	1.2 m³/h	77m	0.75"	2m	<60V	≥1.3 × Pump Power
3DSS1.7-109-48-500	48V	60V–90V	500W	1.7 m³/h	109m	0.75"	2m	<110V	≥1.3 × Pump Power
3DSS2-150-48-750	48V	60V–90V	750W	2 m³/h	150m	0.75"	2m	<110V	≥1.3 × Pump Power
3DSS2-150-72-750	72V	90V–120V	750W	2 m³/h	150m	0.75"	2m	<170V	≥1.3 × Pump Power
3DSS2.2-180-72-1100	72V	90V–120V	1100W	2.2 m³/h	180m	0.75"	2m	<170V	≥1.3 × Pump Power
4DSS2.6-70-48-500	48V	60V–90V	500W	2.6 m³/h	70m	1"	2m	<110V	≥1.3 × Pump Power
4DSS2.6-103-48-600	48V	60V–90V	600W	2.6 m³/h	103m	1"	2m	<110V	≥1.3 × Pump Power
4DSS3.7-112-72-750	72V	90V–120V	750W	3.7 m³/h	112m	1"	2m	<170V	≥1.3 × Pump Power

Note: Model selection should be based on actual well depth, required flow, sunshine conditions, and solar panel configuration.

DC Screw Solar Pump Technical Data Image

Technical Data Image

DC Screw Solar Pump Performance Curve

Hydraulic Performance Curve

Applications

Deep Well Water Supply

Especially suitable for deep well water lifting where higher head is required and stable clean water delivery is needed.

Household & Rural Use

A practical solution for rural homes, villages, and remote sites without reliable electricity supply.

Small Irrigation Systems

Can be used for garden irrigation, orchard watering, and small-scale agricultural projects requiring dependable daily water supply.

Packing & Accessories

The pump and controller can be packed securely for export shipment. Standard accessories and installation parts help simplify transportation, on-site installation, and daily maintenance.

Export standard protective packing
Controller packed separately for safety
Installation kits and spare parts available
Suitable for sea and land transportation
Convenient for project and distributor orders

DC Screw Solar Pump Packing Image

Packing & Installation Kits

System Connection

DC Screw Solar Pump Wiring Diagram

Solar Controller Wiring Diagram

How the System Works

The DC screw solar water pump works with solar panels through a dedicated controller. The controller regulates input power and helps maintain stable pump operation under changing sunlight conditions.

Solar panel supplies DC power to the system
Controller manages startup, protection, and pump operation
Pump lifts water from deep wells or boreholes
Water level control can be added when required
System can be designed according to local project conditions

How to Calculate Pump Head

Head Calculation Reference

How to Select the Right Model

Screw solar pumps are commonly selected for projects where well depth is greater and stable head performance is more important than very large flow. Before choosing a model, customers should confirm water level depth, required daily water volume, tank height, and actual sunshine conditions.

Correct model selection helps the system run more efficiently and ensures the solar panel and controller are properly matched with pump voltage and power.

Confirm well depth and dynamic water level
Check required flow and vertical lifting distance
Match solar panel voltage and power carefully
Choose screw pump models for deep well high-head demand

FAQ

1. What is the main advantage of a screw solar pump?

A screw solar pump is especially suitable for deep wells and high-head applications where stable lifting performance is required.

2. Can this pump be used in off-grid areas?

Yes. It is designed for solar-powered off-grid water supply projects and can work with solar panels through a DC controller.

3. Which applications is this pump suitable for?

It is suitable for deep well water lifting, household water supply, rural water projects, livestock watering, and small irrigation systems.

4. How do I choose the right model?

Please provide required flow, head, well depth, water level, and local solar conditions. We can recommend a suitable model and solar panel configuration.

Need a Deep Well Solar Pump Solution?

Tell us your well depth, required flow, head, and application. We can help you choose the right DC screw solar water pump model and recommend a matching solar power configuration.
